Carbon ,alloy,stainless Steel
as per request
as per request
Availability: | |
---|---|
Quantity: | |
Detailed Image
Standard
COLD DRAWN SEAMLESS STEEL TUBE | |||
Standards | Steel Grades | Size Range | |
DIN | 2391 | ST35/45/52 | OD2 - 60mm × WT0.3 -10mm |
1629 | ST37/44/52 | OD2 - 60mm × WT0.3 -10mm | |
1630 | ST37.4/44.4/52.4 | OD2 - 60mm × WT0.3 -10mm | |
2445 | ST35/ST52/ST37.4//52.4 | OD2 - 60mm × WT0.3 -10mm | |
73000 | ST 35 / 45 / 52/ 37.4 / 44.4 /52.4 | OD3 - 30mm × ID 1 - 12.5 mm | |
GB/T | 8162 | 10/20/16Mn/35/45/30CrMo/42CrMo/etc | OD2 - 60mm × WT0.3 -10mm |
8163 | 10/20/16Mn/35/45/30CrMo/42CrMo/etc | OD2 - 60mm × WT0.3 -10mm | |
3639 | 10/20/16Mn/35/45/30CrMo/42CrMo/etc | OD2 - 60mm × WT0.3 -10mm | |
3093 | 10/20/16Mn/35/45/30CrMo/42CrMo/etc | OD3 - 30mm × ID 1 - 12.5 mm | |
EN | 10305-1 | E215/235/255/355 | OD2 - 60mm × WT0.3 -10mm |
10305-4 | E215/235/255/355 | OD2 - 60mm × WT0.3 -10mm | |
ASTM | A822-A450 | A822 | OD2 - 60mm × WT0.3 -10mm |
A179-A450 | A179 | OD2 - 60mm × WT0.3 -10mm | |
A519 | 1010/1015/1025/1030/1045/4130/4140/etc | OD2 - 60mm × WT0.3 -10mm | |
SAE | J524 | Low carbon steel | OD2 - 60mm × WT0.3 -10mm |
J529 | Low carbon steel | OD3 - 30mm × ID 1 - 12.5 mm | |
JIS | G3445 | STKM11A/12A/12B/12C/13A/13B/13C/S45C/etc | OD2 - 60mm × WT0.3 -10mm |
G3455 | STS35/38/42/49 | OD3 - 30mm × ID 1 - 12.5 mm | |
ISO | 8535 | ST 35 / 45 / 52/ 37.4 / 44.4 /52.4 | OD3 - 30mm × ID 1 - 12.5 mm |
NF | A49-310 | TU37b/TU52b | OD2 - 60mm × WT0.3 -10mm |
BS | 3602 | CFS 360 | OD2 - 60mm × WT0.3 -10mm |
6323(-4) | CFS2/CFS3/CFS4/CFS5 | OD2 - 60mm × WT0.3 -10mm | |
ASTM | A269 | 304,304L, 316, 316L | OD2 - 60mm × WT0.3 -10mm |
EN | 10216-5 | 1.4401, 1.4404 | OD2 - 60mm × WT0.3 -10mm |
Cylinder steel pipes, often referred to as cylinder tubes or hydraulic cylinder tubes, find application in a variety of industries and are primarily used for the construction of hydraulic cylinders and pneumatic cylinders. These cylinders, in turn, serve as critical components in numerous applications across different sectors. Here are some common applications of cylinder steel pipes:
1. Automotive Industry:
Hydraulic cylinders in vehicles control various functions, including power steering, braking systems, and convertible top mechanisms. Cylinder steel pipes are integral to these hydraulic systems.
2. Construction Machinery:
Heavy construction equipment like excavators, bulldozers, and cranes rely on hydraulic cylinders for tasks like digging, lifting, and moving heavy materials.
3. Manufacturing Machinery:
Hydraulic cylinders are employed in manufacturing equipment for operations such as pressing, bending, and material handling. These cylinders are vital for maintaining precision and reliability.
4. Agricultural Machinery:
Tractors, plows, and harvesters utilize hydraulic cylinders for functions such as lifting and tilting. Cylinder steel pipes are instrumental in these hydraulic systems.
5. Aerospace Industry:
Aircraft and spacecraft employ hydraulic and pneumatic cylinders for various applications, including landing gear operation, wing flaps, and cargo handling systems.
6. Marine Industry:
Ships and boats use hydraulic cylinders for functions like steering systems, anchor handling, and cargo loading and unloading.
7. Industrial Automation:
Robotic arms and automation systems rely on hydraulic and pneumatic cylinders for precise and controlled movement.
8. Material Handling:
Conveyor systems and forklifts employ hydraulic cylinders for lifting and transporting goods in warehouses and manufacturing facilities.
9. Agriculture:
Hydraulic cylinders are used in agricultural equipment like irrigation systems, plows, and crop harvesters to enhance efficiency and productivity.
10. Oil and Gas Industry:
In the oil and gas sector, hydraulic cylinders are used in wellhead control systems and offshore equipment for functions such as valve operation and drilling operations.
11. Mining:
Mining equipment, including drilling rigs, crushers, and conveyors, use hydraulic cylinders for various tasks related to mineral extraction and processing.
12. Civil Engineering:
Hydraulic cylinders are employed in civil engineering applications such as bridge construction, dam operation, and pile driving.
13. Medical Equipment:
Hydraulic and pneumatic cylinders are used in medical devices and equipment, including patient lifts, hospital beds, and diagnostic machinery.
14. Environmental Control:
Hydraulic cylinders play a role in waste management systems for compacting and transporting refuse.
15. Energy Generation:
Hydraulic cylinders are used in power generation facilities, including hydroelectric dams, for tasks such as gate operation.
Cylinder steel pipes are versatile and dependable components in hydraulic and pneumatic systems across a broad spectrum of industries, enabling precise control of movement, force, and pressure. Their durability and reliability contribute to the efficiency and performance of the equipment and machinery in these various applications.
